| Model | HIP5548 |
| Rated outpot power(W) | 5500 |
| MAX. PV Charging | 500V |
| Rated battery input Voltage | 48V |
| Parallel Number | 1-6 |
| Application | Home |
| Dimension[W×DxH,mm] | 378×280×103 |
| Net Weight [Kg] | 10.5 |
HIP Series
Pure sine wave output
Advanced SPWM technology
Mains bypass voltage or inverter output can be selected
Provide 4 charging modes
Advanced MPPT technology, the efficiency reaches 99.9%
Design LCD screen to observe dynamic data
ON/OFF rocker switch for AC output control
Power saving mode can reduce no-load loss
Intelligent heat dissipation, prolonging the life of the system
Support lead-acid battery and lithium battery
Perfect protection, with multiple protection functions
| Models | HIP5548 |
| Parallel mode | |
| Permitted parallel number | 1~6 |
| AC mode | |
| Rated input voltage | 220/230Vac |
| Overload/short circuit protection | Circuit breaker |
| Efficiency | >95% |
| Maximum bypass overload current | 40A |
| Inverter mode | |
| Output voltage waveform | Pure sine wave |
| Rated output power (VA) | 5500 |
| Rated output power (W) | 5500 |
| Power factor | 1 |
| Rated output voltage (Vac) | 230Vac |
| Output voltage error | ±5% |
| Output frequency range (Hz) | 50Hz ± 0.3Hz |
| 60Hz ± 0.3Hz | |
| Maximum Efficiency | >92% |
| AC charging | |
| Battery type | Lead acid or lithium battery |
| Maximum charge current(can be set) | 0-60A |
| Charge current error | ± 3Adc |
| Charge voltage range | 40 –58Vdc |
| Short circuit protection | Circuit breaker and blown fuse |
| Circuit breaker specifications | 40A |
| Overcharge protection | Alarm and turn off charging after 1 minute |
| PV charging | |
| Maximum PV open circuit voltage | 500Vdc |
| PV operating voltage range | 120-500Vdc |
| MPPT voltage range | 120-450Vdc |
| Battery voltage range | 40-60Vdc |
| Maximum PV input power | 6000W |
| Maximum PV input current | 22A |
| PV charging current range (can be set) | 0-100A |
| Charging short circuit protection | Blown fuse |
| Wiring protection | Reverse polarity protection |
| Hybrid charging Max charger current specifications (AC charger+PV charger) | |
| Max charger current(can be set) | 0-100A |
| Certified specifications | |
| Certification | CE(IEC62109-1) / CETL(UL 1741 C22.2 NO.107.1) /FCC/SAA |
| EMC certification level | EN61000 |
| Operating temperature range | -10°C to 55°C |
| Storage temperature range | -25°C ~ 60°C |
| Humidity range | 5% to 95% (Conformal coating protection) |
| Noise | ≤60dB |
| Heat dissipation | Forced air cooling, variable speed of fan |
| Communication interface | USB/RS485(WiFi/GPRS)/Dry contact control |
| Dimension (L*W*D) | 426mm*322mm*124mm |
| Weight | 10.5kg |
