| Model | EC-MIN 5.12 |
| Total Energy [kWh] | 5.12 |
| Capacity [Ah] | 100 |
| Nominal Voltage [V] | 51.2 |
| Voltage Range [M] | 44.8-57.6V |
| MAX.Charge & Discharge Current[A] | 100 |
| Dimension[W×DxH,mm] | 480*480*130 |
| Net Weight [Kg] | 42 |
Introduction
Single-button start/stop for easy operation
Engineered for stable, long-term charging and discharging performance
Smart BMS delivers precise monitoring and protection
Supports high-power charge and discharge currents
Reliable performance with premium processors and globally recognized components
Flexible connectivity with RS485 and CAN interfaces
Universal BMS compatibility for effortless inverter integration
Durable lifespan of over 5 years
Fully supports hybrid inverter systems
Up to 8,000 cycles with 80% depth of use
| Model | EC-MIN 5.12 | EC-MIN 16.08 |
| Total Energy [kWh] | 5.12 | 16.08 |
| Capacity [Ah] | 100 | 314 |
| Nominal Voltage [V] | 51.2 | 51.2 |
| Voltage Range [V] | 44.8-57.6 | 44.8-57.6 |
| MAX. Charge & Discharge Current [A] | 60 | 150 |
| Peak Charge & Discharge Current [A] (for 10 sec.) | 100 | 200 |
| Product Dimension(MM) | 480*480*130MM | 420*200*790MM |
| Net Weight [Kg] | 46 | 109 |
| Scalable | 1~16 in parallel | |
| Communication | CAN,RS485 | |
| Communicated Inverter | GOODWE/Victron/SOFAR/DEYE/Growatt/MEGAREVO/SRNE | |
| Enclosure Protection Rating | IP21 | |
| Charging Temp Range [°c] | 0~55 | |
| Discharging Temp Range [℃] | -10 ~55 | |
| Cycle Life | ≥8,000 Cycle@ 80% DOD / 25℃ / 0.5C, 60%EOL | |
| Warranty | 5 years | |
| Certification | IEC62619,UN38.3,CE | |
